Return Taper Self-aligning Idlers
Tapered rollers guide the return belt centrally.
| Belt Width | Model | Friction Roller Type | D1 | D2 | Bearing No. | L | H1 | H2 | E | A | P | Q | D | MASS (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 800 | -080-108-305 | BK TR-108(159)-305-445 | 108 | 159 | 305 | 445 | 217 | 452 | 1150 | 1090 | 160 | 90 | M12 | 78.8 |
| 1000 | -100-108-305 | BK TR-108(176)-305-560 | 108 | 176 | 305 | 560 | 254 | 532 | 1350 | 1290 | 160 | 90 | M16 | 91.5 |
| 1200 | -120-108-306 | BK TR-108(194)-306-680 | 108 | 194 | 306 | 680 | 272 | 557 | 1600 | 1540 | 180 | 90 | M16 | 100.1 |
| 1400 | -140-108-306 | BK TR-108(194)-306-780 | 108 | 194 | 306 | 780 | 291 | 578 | 1800 | 1740 | 180 | 90 | M16 | 132.1 |
| 1600 | -160-133-308 | BK TR-133(219)-308-880 | 133 | 219 | 308 | 880 | 326 | 613 | 2050 | 1980 | 300 | 240 | M16 | 177.1 |
| 1800 | -180-133-308 | BK TR-133(219)-308-980 | 133 | 219 | 308 | 980 | 331 | 618 | 2250 | 2180 | 300 | 240 | M16 | 209.6 |
